| USAGE AREAS |
| ■ Places that need high pressure steam in high capacities, |
■ Pesponds to all kind of working conditions, |
| ■ Places that payattetion on safety and high efficiency, |
■ Providing maintenance and ease of use, |
| ■ Instantaneous steam tracction provides rapid energy conversion, |
■ Eco-friendly due to 3-pass features, |
| ■ Unattandant and constantly running, |
■ Can be used at all places, that need to generate steam,. |
| ■ Places that need high efficiency, |
|
| ADVANTAGES |
| ■ Low risk of explosion due to low water capacity during operation, |
■ Provides lower nitrogen oxide emissions with 3-pass design, |
| ■ Reacts to instantaneous steam traction, due to high steam capacity, |
■ It is possible to provide high efficiency with integrated economizer, |
| ■ With the addition of superheater unit can obtain high temperatures at low pressure, |
■ Includes upper and lower dram cleaning domes, |
| ■ Staircase and platform provides easy and safe acces between floor levels and boiler, |
■ Heat loss is prevented by mess wire rockwool insulation, |
| ■ Alumina-doped refractory is resistant to high temperature,durable and insulated |
■ Simple to operate and to maintain. |
| ■ Can be used with different types of burners, |
|
| DISADVANTAGES |
■ It is hard to clear pipes.
■ Good water softener system is required. |
|
| FEAUTURES |
| Heat Capacities |
3000-20.000kg/h (2.093-13.953kW) |
| Boiler Efficiency |
%90-92 (non eko)
%97 (eko)
|
| Max.Operating Pressure |
3-45bar |
| Max.Temperature |
350°C |
| Type |
Cylindrical-Horizontal |
| Fuel |
Liquid (Diesel-Fuel Oil)
Gas (Nature Gas -LNG-CNG-LPG-Biogaz)
|
| Design Code |
CE marked as per Pressure Equipment Directive
(PED 97/23/AT)
|
| Design Standart |
EN 12953 |
| Material |
|
| Upper Drum |
P235GH-P265GH-P295GH-P355GH |
| Lower Drum |
P235GH-P265GH-P295GH-P355GH |
| Lama |
P235GH-P265GH-P295GH-P355GH |
| Tubes |
P235GH-St35.8 |
| Flanges |
P235GH-P265GH |
| Insulation |
Mesh wire rockwool
Colored electrostatic powder coated carbon
steel sheet
|
