| TECNICAL FEUTURES OF WATER TUBE ECONOMIZER |
■ Useful at the places with high pressure,
■ Water circulates inside plain tubes, while gas circuletes out, |
■ Safe and economical,
■ By-pass flap, |
■ Pneumatic or electrical actuators,
■ On the upper side of unit there are air/steam blower nozzles which prevent scaling on tubes, |
■ At the bottom of the unit there is ash collector bunker,
■ Collected ash automatically discharges outside through the air lock and prevents accumulation of ash. |
| TECNICAL FEUTURES OF SMOKE TUBE ECONOMIZER |
■Gas passes through smoke tubes while water circulates out,
■ By-pass flap, |
■ Due to the vertical design, gas fuel particles naturally collapses down.
■ Pneumatic or electrical actuators. |
| ■ At the bottom of the unit there is ash collector bunker, |
■ Collected ash automatically dischanges outside through the air lock and prevents accumulation of ash. |
| ADVANTEGES |
| ■ Provides additional energy by recovering heat ejected from the stack. |
■ Ecofriendly |
| ■ Increase your production capacity and reduce energy bills. |
|
| |
|
| DİSADVANTEGES |
| ■ It creates counter pressure on the water and flue gas side. |
■ Good economizer design is required. |
| |
|
| TECNICAL FEUTURES OF WATER TUBE ECONOMIZER |
| Heat Capacities |
50.000-3.000.000kcal/h |
| Max.Operating Pressure |
3-30bar |
| Max.Temperature |
100-1.200°C |
| Type |
Cylindrical-Horizontal |
| Fuel |
Lump coal, waste mud etc.
|
| Design Code |
CE marked as per Pressure Equipment Directive
(PED 97/23/AT).
|
| Design Standart |
EN 12952/EN 12953 |
| Material |
|
| Rears |
Stainless or Carbon Steel |
| Body |
Stainless or Carbon Steel |
| Tubes |
|
| Flanges |
Stainless or Carbon Steel |
| Insulation |
Mesh wire rockwool
Colored electrostatic powder coated carbon
steel sheet
|
| Dump |
Electrical/Pneumatic |
| TECNICAL FEUTURES OF SMOKE TUBE ECONOMIZER |
| Heat Capacities |
50.000-3.000.000kcal/h |
| Max.Operating Pressure |
3-30bar |
| Max.Temperature |
100-1.200°C |
| Type |
Cylindrical-Horizontal |
| Fuel |
Lump coal, waste mud etc.
|
| Design Code |
CE marked as per Pressure Equipment Directive
(PED 97/23/AT).
|
| Design Standart |
EN 12952/EN 12953 |
| Material |
|
| Rears |
Stainless or Carbon Steel |
| Body |
Stainless or Carbon Steel |
| Tubes |
|
| Flanges |
Stainless or Carbon Steel |
| Insulation |
Mesh wire rockwool
Colored electrostatic powder coated carbon
steel sheet
|
| Dump |
Electrical/Pneumatic |
