| USAGE AREAS |
| ■ Places that use hot oil as fuel, |
■Theere-way valve control ensures precise heat transfer with proportional steam production. |
| ■ While hot aircirculates inside exchangers, at the same time boiling water transformed into saturated steam. |
|
| ADVANTAGES |
| ■ Could be used for generating steam heated water and hot air, |
■ Thermal oil which is used as the heat transfer in the system, does not leaves residues, scale in plumbing and does not constitute corrosion |
| ■ Special conditions for thermal oil are not required, |
■ Thermal insulated |
| ■ Allows access to high temperatures without pressure, |
■ Present ease of usage and maintenance, |
| FEAUTURES |
| Heat Capacities |
100kW - 7000kW |
| Max.Operating Pressure |
3 - 30bar |
| Max.Temperature |
200°C |
| Type |
Cylindrical-Horizontal or Vertical |
| Design Code |
E marked as per Pressure Equipment Directive
(PED 97/23/AT) .
|
| Design Standart |
EN 12953 |
| Material |
Stainless or carbon steel |
| Insulation |
Mesh wire rockwool
Colored electrostatic powder coated carbon
steel sheet
|
