Electrical Steam Generator
Product Description
Technical Data
Documents
Fiyat Listesi
| USAGE AREAS |
| ■ Companies with low investment cost, |
■ Places that do not want to deal with fuel and flue gas problems, |
| ■ Places that need max. 250kg/h - 6bar bar steam, |
■ Places that want to produce steam with electricity and water
water connections only, |
| ■ Easy operation and maintenance, |
■ Can be used safely at all types of business. |
| ADVANTAGES |
| ■ Due to the small water capacity, generates rapid steam and reduces losses in the first operating period, |
■ Hard and unfilterred water can be used for cleaning device, |
| ■ Full automatic and safe, |
■ Heat loss is prevented by mesh wire rockwool insulation, |
| ■ Simple to operate and to maintain, |
■ Alumina-doped refractory is resistant to high temperature, durable and insulated |
| ■ Can easily fit in a small areas, |
■ No need o supervision. |
| DISADVANTAGES |
| ■ Resistance is experienced frequent failures. |
■ Electricity costs are high.Steam production is more expensive
compared to other fuel types. |
| FEAUTURES |
| Heat Capacities |
50-250kg/h (35-175kW) |
| Max.Operating Pressure |
0,5-6bar |
| Max.Temperature |
165°C |
| Type |
Cylindrical-Horizontal or Vertical |
| Fuel |
Electricity |
| Design Code |
CE marked as per Pressure Equipment Directive
(PED 97/23/AT)
|
| Design Standart |
EN 12953 |
| Material |
|
| Body |
Resistance 2" stainless steel
P235GH-P265GH-P295GH-P355GH |
| |
|
| Flanges |
P235GH-P265GH |
| Insulation |
Mesh wire rockwool
Colored electrostatic powder coated carbon
steel sheet
|
| Equipment |
Boiler and safety equipment,
Condansate tank,
Feed pump.
Water softener,
Electric panel.
|
