| USEGA AREAS |
| ■ Places that need high pressure steam, |
■ Places that need pure steam,due to this can be made of stainless steel |
| ■ Can easily fit in a small boiler room, |
■Can be activated immediately with electricity, water, fuel and chimney connection, |
| ■ Places that need rapid steam, |
■ Can be used at all places, that wish to consume less fuel with high efficiency. |
| ■ May be installed on the orking space of the enterprise, due low water capacity, |
| ADVANTAGES |
| ■ Provides lower pollutant emmisions,with less than 1,3MW/m³ furnace load, |
■ Due to the ( low water capacity ) , generates rapid steam and reduces losses in the first operating period, |
| ■ Temperature of the flue gas reducing condensation temperature and provides high efficiency with economizer, |
■ Has a low capacity, during operating period.No danger of explosions therefore can be safely used at the building without special precautions, |
| ■ For pure steam, could be made of stainless steel if needed, |
■ Heat loss is prevented by mesh wire rockwool insulation, |
| ■ Alumina-doped refractory is resistant to high temperature,durable and insulated, |
■ The tubes bundles are easy accessible through back and front large man holes, which also means general good access for inpection and cleaning of the inner parts of the boiler, |
| ■ May be installed on the working space of the enterprise, |
■ It is a compact structure consisting of; burner, fittings, pumps, water softener unit and condansate tank, |
| DISADVANTAGES |
| ■ Water parts could not be fixed in case of occlusion.You may need to change the complete serpantines. |
| FEAUTURES |
| Heat Capacities |
200-3.000kg/h (140-2.093kW) |
| Boiler Efficiency |
%90-92 (non eco)
%97 (eco)
|
| Max.Operating Pressure |
3-30bar |
| Max.Temperature |
350°C |
| Type |
Cylindrical-Horizontal |
| Fuel |
Liquid (Diesel-Fuel Oil)
Gas (Nature Gas-LNG-CNG-LPG-Biogaz)
|
| Design Code |
CE marked as per Pressure Equipment Directive
(PED 97/23/AT)
|
| Design Standart |
EN 12953 |
| Material |
|
| Furnace |
Heat resistant steel sheet in grade HI-HII
P235GH-P265GH-P295GH-P355GH
|
| Shell |
P235GH-P265GH-P295GH-P355GH
|
| Tubes |
P235GH-St35.8
|
| Flanges |
P235GH-P265GH
|
| Insulation |
Mesh wire rockwool
Colored electrostatic powder coated carbon steel sheet
|
| Refractory |
Resistance to high temperatures (1500°C),
thermal shock and overload,impact strength
|
