| USAGE AREAS |
| ■ Places that need high temperatures under low pressures. |
■ Can be converted on to Gas-Liquid fired system, |
| ■ Places that aims to recude fuel coast, |
■ Places that need complete set of boiler room, |
| ■ Pipes scale formation or accumulation of sludge in short term is prevented, |
■ Presents ease of usage and maintenance, |
| ■ Special conditions for thermal oil are not required, |
■ Can be activated immediately with electricity, oil and chimney connection. |
| ADVANTAGES |
| ■ Thermal oil which is used as the heat transfer in the system, does not leaves residues, scale in plumbing and does not constitute corrosion, |
■ Special conditions for thermal oil are not required, |
| ■ Thermal insulated |
■ Allows access to high temperatures without pressure, |
| ■ Could be also used for generating steam, super heated water and hot air, |
■ Staircase and platform provides easy and safe acces between floor levels and boiler, |
| ■ Heat loss is prevented by mesh wire rockwool insulation, |
■ Alumina-doped refractory is resistant to high temperature,durable and insulated |
| ■ Simple to operate and to maintain, |
■ It is a compact structure consisting of; burner, pumps, fixtures, degasser, expansion tank, thermal oil reserve tank, chimney and electrical panel. |
| FEAUTURES |
| Heat Capacities |
100.000-5.000.000kcal/h |
| Boiler Efficiency |
%80-82 |
| Max.Operating Pressure |
3-10 bar |
| Max.Temperature |
300°C |
| Type |
Cylindrical-Horizontal |
| Fuel |
Over 5mm Coal and solid fuel |
| Design Code |
CE marked as per Pressure Equipment Directive
(PED 97/23/AT) .
|
| Design Standart |
EN 12953 |
| Material |
|
| Shell |
P235GH-P265GH |
| Tubes |
P235GH-St35.8 |
| Flanges |
P235GH-P265GH |
| Insulation |
Mesh wire rockwool
Colored electrostatic powder coated carbon
steel sheet
|
| Refractory |
Resistance to high temperatures (1500 °C),
thermal shock and overload, high impact strenght. |
| Stocker |
Inner pot resistant to high teppeterus. Pot provides high combustion efficiency and ensuring long life |
