| USAGE AREAS |
| ■Places that sudden steam consumption, |
■Present ease of usage and maintenance, |
| ■Places that need high steam capacity, |
■In all kind businesses which need to steam with more ecofriendly
because of 3 pass feautures can be use. |
| ■Unattandant and constantly, |
■Responds to all kind of working conditions, |
| |
|
| ADVANTAGES |
| ■ High efficiency, |
■Provides lower nitrogen oxide emissions with 3 pass design, |
| ■Provides lower pollutant emissions, with less than 1,3MW/m³ furnace load, |
■It has a large volume of steam, so respond to sudden steam traction, |
| ■Temperature of the flue gas reducing condensation temperature provides high efficiency with economizer, |
■With the addition of superheater unit can obtain high temperatures at low pressure, |
| ■Radiation loss prevented by rear smoke box and water cooler system, |
■Staircase and platform provides easy and safe acces between floor levels and boiler, |
| ■Heat loss is prevented by mesh wire rockwool insulation, |
■Alumina-doped refractory is resistant to high temperature,durable and insulated |
| ■Simple to operate and to maintain, |
■Can be used with different types of burners, |
| DISADVANTAGES |
■At first running, consumed more energy because of the large
volume steam, |
■Physical size maybe an issue. |
| FEAUTURES |
| Heat Capacities |
500-20.000kg/h (349-13.953kW) |
| Boiler Efficiency |
%90-92 (non eco)
%97 (eco) |
| Max.Operating Pressure |
3-30bar |
| Max.Temperature |
350°C |
| Type |
Cylindrical-Horizontal |
| Fuel |
|
Liquid (Diesel-Fuel Oil)
Gas (Nature Gas -LNG-CNG-LPG-Biogaz)
|
|
| Design Code |
CE marked as per Pressure Equipment Directive
(PED 97/23/AT) .
|
| Design Standart |
EN 12953 |
| Material |
|
| Furnace |
Plain/Corrugated heat resistant steel sheet in
grade HI-HII |
| Rears |
Heat resistant steel sheet in grade HI-HII
P235GH-P265GH-P295GH-P355GH
|
| Shell |
P235GH-P265GH-P295GH-P355GH |
| Tubes |
P235GH-St35.8 |
| Bar Stays |
P245GH |
| Flanges |
P235GH-P265GH |
| Insulation |
Mesh wire rockwool
Colored electrostatic powder coated carbon
steel sheet
|
| |
|
| Refractory |
Resistance to high temperatures (1500 °C),
thermal shock and overload, high impact strenght |
