| USAGE AREAS |
| ■ Places that need rapid steam in high capacity, |
■ Unattandant and constantly running, |
| ■ Through radiation combustor 2 curret flama return burns unburned gages and increases the efficiency of combustion. |
■ Since the heating surface is low, can esily fit in a small areas, |
| ■ Places that need high efficiency, |
■ Providing maintenance and ease of use, |
| ■ Places that instantaneous steam consumption, |
■ Compared to other systems need less investments, |
| ■ Can be used at all places, that need to generate steam, |
|
| ADVANTAGES |
| ■ Provides high efficiency and long lasting energy savings, |
■Provides lower pollutant emmisions, with less that 1,3MW/m³ furnace load, |
| ■ Preffered at places that need rapid steam, |
■ It has not been extreme thermal loads to unit heating surface, |
| ■Temperature of the flue gas reducing condensation temperature provides high efficiency with economizer, |
■ With the addition of superheater unit can obtain high temperatures at low pressure, |
| ■Staircase and platform provides easy and safe acces between floor levels and boiler, |
■ Heat loss is prevented by mesh wire rockwool insulation |
| ■Alumina-doped refractory is resistant to high temperature,durable and insulated |
■ Simple to operate and to maintain, |
| ■Can be used with different types of burners, |
■ Can easily fit in a small areas, |
| ■That type of boiler is more affordable than scotch steam boilers. |
|
| DISADVANTAGES |
| ■ Since is has not 3-pass features, do not provide low nitrogen oxide emissions. |
■ Not long lasting as boilers with 3-pass design. |
| FEAUTURES |
| Heat Capacities |
80.000-3.000.000kcal/h (93-3488kW) |
| Boiler Efficiency |
%90-92 |
| Max.Operating Pressure |
5bar |
| Max.Temperature |
90°C |
| Type |
Cylindrical-Horizontal |
| Fuel |
Liquid (Diesel-Fuel Oil)
Gas (Nature Gas -LNG-CNG-LPG-Biogaz)
|
| Design Code |
CE marked as per Pressure Equipment Directive
(PED 97/23/AT)
|
| Design Standart |
EN 12953 |
| Material |
|
| Furnace |
P235GH-P265GH |
| Rears |
P235GH-P265GH |
| Shell |
P235GH-P265GH |
| Tubes |
P235GH-St37.2 |
| Flanges |
P235GH-P265GH |
| Insulation |
Mesh wire rockwool
Colored electrostatic powder coated carbon
steel sheet
|
| Refractory |
Resistance to high temperatures (1500 °C),
thermal shock and overload, high impact strenght |
