| USAGE AREAS |
| ■ Water piped prior stove provides high capacities of steam , |
■ Safe and fully automatic, |
| ■ Places that want to use coal as fuel, |
■ Places that aim to convert system on to Gas-Liquid |
| ■ Places that aims to reduce fuel costs, |
■ Can be activated immediately with electricity, water fuel and stack connection, |
| ■ Places that need steam, |
■ Can be used at all places, that wish to consume less fuel with high efficiency, |
| ■ Places that need complete set of boiler room, |
|
| ADVANTAGES |
| ■ Prior stove provides better burning and emissions are in desired size, |
■ Easier to clean ashes, |
| ■Multiple stockers provide high capacities of steam , |
■ Provides lower nitrogen oxide emissions with 3-pass desing, |
| ■ It is a compact structure consisting of; burning stocker, fixtures, pump, water softener unit and condensate tank. |
■ Staircase and platform provides easy and safe acces beween floor levels and boiler, |
| ■Simple to operate and to maintain, |
■ Heat loss is prevented by mesh wire rockwool insulation, |
| ■Alumina-doped refractory is resistant to high temperature, durable and insulated, |
■Can be converted on to Gas-Liquid system when needed, |
| ■Can easily fit in a small areas. |
|
| DISADVANTAGES |
| ■Coal make ash that accumulates on the interior of the boiler as slag. To increase boiler efficiency you will have to remove slag on a regular basis. |
■ Air ducts are clogged in stocker. Before cleaning, incline of the transport spirals is required. |
| FEAUTURES |
| Heat Capacities |
1500 - 10.OOOkg/h (1.046 - 6976kW ) |
| Boiler Efficiency |
80% |
| Max.Operating Pressure |
3-16 bar |
| Type |
Cylindrical-Horizontal |
| Fuel |
Lumb Coal, Bark |
| Design Code |
CE marked as per Pressure Equipment Directive
(PED 97/23/AT)
|
| Design Standart |
EN 12953 |
| Material |
|
| Furnace |
Plain/Corrugated heat resistant steel sheet in grade HI-HII |
| Rears |
Heat resistant steel sheet in grade HI-HII
P235GH - P265GH - P295GH- P355GH
|
| Shell |
P235GH - P265GH - P295GH - P355GH |
| Prior Stove |
P235GH - St35.8 |
| Tubes |
P235GH - St35.8 |
| Bar stays |
P245GH |
| Flanges |
P235GH - P265GH |
| Insulation |
Mesh wire rockwool
Colored electrostatic powder coated carbon
steel sheet
|
| Refractory |
Resistance to high temperatures (1500 °C),
thermal shock and overload, high impact strenght |
