| USEGA AREAS |
| ■ Places that need less steam by firing pellet, |
■ May be installed on the working space of the enterprise, due to low water capacity, |
| ■ Places that for from city without any gas connection, |
■ Can be activated immediately with electricity water, fuel and stack connection, |
| ■ Places that need rapid steam, |
■ Can be used at all places, that wish to consume less fuel with high efficiency, |
| ■ Could be used poor water quality for cleaning. |
|
| ADVANTAGES |
| ■ Due to the ( low water capacity ) , generates rapid steam and reduces losses in the first operating period, |
■ Heat loss is prevented by mesh wire rockwool insulation, |
| ■ Heat loss is prevented by mesh wire rockwool insulation, |
■ Simple to operate and to maintain |
| ■ It is a compact structure consisting of; burner, fittings, pumps, water softener unit and condansate tank, |
■ Can easily fit in a small areas. |
| FEAUTURES |
| Heat Capacities |
100-1.500kg/h (70-1.046kW) |
| Boiler Efficiency |
%85-92 |
| Max.Operating Pressure |
3-10bar |
| Type |
Cylindrical-Horizontal |
| Fuel |
Pellet, olive seeds |
| Design Code |
CE marked as per Pressure Equipment Directive
(PED 97/23/AT)
|
| Design Standart |
EN 12953 |
| Material |
|
| Furnace |
Plain heat resisyant steel sheet in grade HI-HII |
| Rears |
Heat resistant steel sheet in grade HI-HII |
| Shell |
P235GH-P265GH |
| Dom |
P235GH-P265GH |
| Tubes |
P235GH-St35.8 |
| Bar stays |
P245GH |
| Flanges |
P235GH-P265GH |
| Insulation |
Mesh wire rockwool
Colored electrostatik powder coated carbon steel sheet
|
| Refraktory |
Resistance to high temperatures (1500°C),
thermal shock and overload,impact strength |
