High Temperature Steam Boilers
Product Description
Technical Data
Documents
Fiyat Listesi
| High Temperature Steam Boilers (250°C) |
| ■ Provides high capacity hot air, |
■ Usage Areas: Heating, ventilation, can be installed on all kind industirial facilities, |
■ Mostly used for heating purposes,
■ System set icludes: cold air fan, burner, electrical panel. |
■ Made of stainless steel, |
| FEAUTURES |
| Volume |
350.000-3.000.OOOkca l/h |
| Max.Operating Pressure |
0,5-5 bar |
| Max.Temperature |
250°C |
| Type |
Cylindrical-Horizontal |
| Fuel |
Liquid (Diesel-Fuel Oil)
Gas (Nature Gas -LNG-CNG-LPG-Biogaz)
Solid (Coal-Biomas-Wood-Waste)
|
| Design Code |
CE marked as per Pressure Equipment Directive
(PED 97/23/AT).
|
| Design Standart |
EN 12953 |
| Material |
|
| Furnace |
Stainless Steel |
| Tubes |
Stainless Steel |
| Shell |
Stainless Steel |
| Flanges |
Stainless Steel |
| Insulation |
Mesh wire rockwool
Colored electrostatic powder coated carbon
steel sheet
|
