Solid Fuel Fired with Stocker
Product Description
Technical Data
Documents
Fiyat Listesi
| USAGE AREAS |
| ■ Can be used at all places, that use coal and need to produce rapid steam in low capacities |
■ Can be used at all places, that aim to consume less fuel with high efficiency. |
| ■ Can be converted on to Gas-Liquid fired system, |
■ Can be activated immediately with electricity, water fuel and chimney connection, |
| ■ Ready for use boiler room set, |
■ Can be used at all places, that wish to consume less fuel with high efficiency, |
| ■ Safe and fully automatic, |
|
| ADVANTAGES |
| ■ Due to the semi-cylindrical feature flame length is sufficient and ash cleaning facilities are comfortable, |
■ Due to thw low watwer capacity, generates rapid steam and reduces losses at the first operating period, |
| ■ Temperature of the flue gas reducing condensation temperature and provides high efficiency with economizer |
■ Provides lower nitrogen oxide emissions with 3-pass desing, |
| ■ Radiation loss is prevented by rear smoke box and water coler system, |
■ Staircase and platform provides easy and safe acces beween floor levels and boiler, |
| ■ Heat loss is prevented by mesh wire rockwool insulation, |
■ Alumina-doped refractory is resistant to high temperature, durable and insulated, |
| ■ Simple to operate and to maintain, |
■ Can easily fit in a small areas, |
| ■ Can be converted on to Gas-Liquid system, |
■ It is a compact structure consisting of; burning stocker, fixtures, pump, water softener unit and condensate tank. |
| DISADVANTAGES |
■ Coal ash accumulates on the interior of the boiler as slog. To increase boiler efficiency ou will have to remote slag on a regular basis.
■ Spare parts are required.
|
■ Air ducts are clogged in stocker. Before cleaning, incline of the transport spirals is required. |
| FEAUTURES |
| Heat Capacities |
100-1.500kg/h (70-1.046kW) |
| Boiler Efficiency |
%82-87 |
| Max.Operating Pressure |
3-10 bar |
| Type |
Cylindrical-Horizontal |
| Fuel |
Over 5mm coal and solid fuel |
| Design Code |
CE marked as per Pressure Equipment Directive
(PED 97/23/AT) |
| Design Standart |
EN 12953 |
| Malzeme |
|
| Furnace |
Plain heat resistant steel sheet in grade HI-HII |
| Rears |
Heat resistant steel sheet in grade HI-HII |
| Shell |
P235GH-P265GH |
| Dom |
P235GH-P265GH |
| Tubes |
P235GH-St35.8 |
| Bar Stays |
P245GH |
| Flanges |
P235GH-P265GH |
| Insulation |
Mesh wire rockwool
Colored electrostatic powder coated carbon
steel sheet
|
| Refractory |
Resistance to high temperatures (1500 °C),
thermal shock and overload, high impact strenght |
